System Overview
Our company's intelligent high-bay warehouse system is a modern warehousing solution that integrates high-bay racking, rail-guided stacker cranes (STLs), RGV (rail-guided vehicle) shuttles, and an intelligent management system (WMS/WCS). Through highly automated material handling and information management, the system enables efficient, accurate, and unmanned storage and retrieval of goods, significantly improving space utilization and operational efficiency. It serves as the core infrastructure for modern enterprises to achieve intelligent and digital warehousing.
Core Products and Technologies
1. Intelligent Storage and Retrieval System (AS/RS)
The intelligent storage and retrieval system consists of high-rise racks, rail-guided stacker cranes, inbound and outbound conveying systems, an automated control system (WCS), and a warehouse management system (WMS), forming a complete automated material storage and retrieval system.
• High Space Utilization: High-rise racking fully utilizes vertical space, saving approximately 50%-70% of floor space compared to traditional flat warehouses.
• Fully Automated Operation: From goods entry, shelving, storage, to outbound delivery, the system automatically schedules the entire process, enabling unmanned "dark warehouse" operations.
• Information Management: The WMS system provides real-time monitoring, precise management, and intelligent analysis of inventory information, ensuring visibility, traceability, and manageability.
• High Scalability and Flexibility: A modular design allows for flexible expansion of system scale and functionality based on business growth.
2. Rail-mounted aisle stacker crane (Stacker Crane) The stacker crane is the core handling equipment of the high-bay warehouse, responsible for precise storage and retrieval operations in the aisles of the shelves. Our company provides two series of straight rail type and curved rail type to meet the needs of different scenarios.
(1) Straight rail type stacker crane: Features: high speed and high efficiency, smooth operation. Suitable for scenarios with high storage and retrieval frequency and large throughput. Typical parameters: horizontal speed 0-180 m/min, lifting speed 0-100 m/min, addressing accuracy ±2mm.
(2) Curved rail type stacker crane: Features: can realize multi-aisle operation with one machine, high flexibility, and more economical initial investment. Typical parameters: horizontal speed 0-100 m/min, load capacity up to 1-8 tons, addressing accuracy ±3mm.
3. RGV (Rail Guided Vehicle)
The RGV is an automated transport vehicle that runs on fixed tracks. In high-bay warehouses, it is primarily used to transport goods between loading and unloading platforms and rack aisles, seamlessly integrating with stacker cranes and conveyor lines.
• Efficient Integration: Serving as a logistics hub, it quickly and accurately delivers goods to designated locations, creating a continuous and smooth logistics flow.
• Flexibility and Reliability: Different routes, such as straight and circular, can be designed to meet process requirements. Powered by a closed busbar, it is stable and reliable.
• Typical Parameters: Travel speed 0-180 m/min, load capacity ≤1000 kg, address recognition accuracy ±5 mm.
System Benefits
• Cost Reduction and Efficiency Improvement: Significantly reduces reliance on manual labor, reducing labor costs and human errors, and increasing operational efficiency severalfold.
• Lean Management: Enables real-time and accurate updates of inventory data, helping companies implement lean inventory management and reduce capital tied up.
• Quality Improvement: Utilizes standard pallet/carton storage and automated handling to effectively minimize damage and ensure material quality.
• Enhanced Safety: The system incorporates multiple built-in safety mechanisms (such as anti-collision, position limits, and emergency stops) to ensure the safety of personnel, goods, and equipment.
• Data-Driven: Provides accurate and timely logistics data to upper-layer systems such as ERP and MES, becoming a key component of digital factories.
Application Industries
This system and equipment are widely used in industries with high warehouse management standards:
• New energy industry: High-precision warehouse management of lithium battery raw materials and finished products.
• Cold chain logistics industry: Food, pharmaceuticals, and other goods that require temperature-controlled storage.
• Automotive manufacturing: Efficient storage and serialized distribution of parts and accessories.
• Home appliance and electronics industry: Automated warehousing of high-value components and finished products.
• Pharmaceutical and chemical industry: Complying with GMP and other regulations, achieving batching and traceability management.
• Apparel and retail industry: Distribution centers with a wide variety of SKUs require efficient sorting and rapid response.
• Transportation hubs such as airports and railways: Modern warehouse management of large-scale parts and supplies.
Why choose Forward Technology?
• Independently developed core technology and equipment: From stacker cranes and RGVs to the core control system (WCS), we possess independent R&D and production capabilities, ensuring system stability and reliability.
• One-stop turnkey solutions: We provide full lifecycle services, from solution planning, equipment manufacturing, software development, installation and commissioning, to training and maintenance.
• In-depth industry understanding and customization capabilities: We deeply understand the process and logistics pain points of various industries and can provide customized solutions that best meet our customers' specific needs.
• Excellent project delivery capabilities: We have extensive experience integrating large-scale projects, ensuring successful project delivery on time, to quality, and on budget.
• Full-process intelligent experience: We integrate advanced technologies such as the Internet of Things and data visualization to provide customers with a new experience in intelligent, convenient, and efficient warehouse management.
